Introduction
In general, bacterial entomopathogens have low virulence and are opportunistic. Bacteria belonging to the genus
Bacillus however have proved to be highly effective control agents as they infect and kill a range of orders. Bacilli
are Gram positive, produce spores and are found abundantly in the soil. The bacteria typically infect the larval
stage via ingestion and are transmitted horizontally. However, lack of contact action means transmission is low and
therefore Bacillus pathogens need frequent re-application. Fortunately, however, they are cheap to grow and
produce.
Detailed Example: Bacillus thuringiensis
Bacillus thuringiensis (Bt) is the most widely used microbial biopesticide and is an
example of inundative control. It has been deemed the safest insecticide on the
market by the World Health Organisation (Ehlers, 2011). Bt targets species in the
orders of Lepidoptera, Diptera and Coleoptera, pests of vegetables, fruits, cotton,
rice and maize. Bt was first used in the late 1950s and by 1998, around 200 Bt
products were registered in America (Harper, 2006; Lacey et al, 2001).
Infection Process
During sporulation Bt produces a protein pro-toxin crystal, located in parasporal inclusion bodies (Figure 1).
Crystals ingested by larvae dissolve within the alkaline midgut and are cleaved by gut proteases to form delta-
endotoxins. Bt is therefore selectively lethal to organisms with an alkaline gut. The toxin binds to specific gut
receptors which damages the gut via pore formation and membrane transport disruption which results in cell
paralysis (Lacey et al, 2001). The insect stops feeding and dies within 2-24 hours (Copping and Menn, 2000). The
infection is not usually transmitted to new hosts (i.e. it is a dead end infection).
Crystalline proteins are encoded by cry genes located on extra-chromosomal plasmids in the bacterial cell
(Copping and Menn, 2000). More than 200 genes have been identified which code for a different toxin in Bt. Each
toxin is specific to a particular insect species because it binds to a different gut receptor.
Other Bacillus species successfully used as MCAs
These species are used on a smaller scale than Bt but are still very important.
1.
Bacillus papillae targets the order scarabaeids and in particular causes ‘milky disease’ in the Japanese
beetle. This species was the first entomopathogen to be released onto the market in America and was
registered in 1939 (Harper, 2006).
2.
Bacillus sphaericus has been used in Europe and Africa to kill mosquito larvae, in particular Culex species
(Copping and Menn, 2000).
Figure 1 Crystals of Bt toxin
Genetically Modified Bt Crops
An alternative to applying the toxin producing bacteria directly onto a crop, is the controversial technique of
taking toxin coding genes and putting them into plants. Genetically modified Bt-crops are therefore engineered
to produce a toxin themselves which kills any insect feeding on it. In America, Bt-crops such as cotton, tobacco,
maize and rice have been grown since 1996 (Nicholson, 2007). Transgenic plants that produce insecticidal
proteins are highly effecitive at protecting the whole plant from phytophagous (plant-eating) invertebrates (i.e.
protects parts inaccessible to foliar sprays).
Benefits and Costs
Bt has similar benefits to chemical pesticides and therefore it is no surprise that 70-80% of all spending goes on
this control agent (Harper, 2006). This non-living toxin acts fast, has broad activity and is insect specific. Similar to
chemical pesticides however, resistance is starting to emerge in some populations. The diamondback moth,
Plutella xylostella for example is a serious worldwide pest of cruciferae vegetables that has developed resistance
to Bt biopesticides (Harper, 2006).
